Memory

from langgraph.checkpoint.memory import InMemorySaver  # [!code highlight]
from langgraph.graph import StateGraph

checkpointer = InMemorySaver()  # [!code highlight]

builder = StateGraph(...)
graph = builder.compile(checkpointer=checkpointer)  # [!code highlight]

graph.invoke(
    {"messages": [{"role": "user", "content": "hi! i am Bob"}]},
    {"configurable": {"thread_id": "1"}},  # [!code highlight]
)

from langgraph.checkpoint.postgres import PostgresSaver

DB_URI = "postgresql://postgres:postgres@localhost:5432/postgres?sslmode=disable"
with PostgresSaver.from_conn_string(DB_URI) as checkpointer:  # [!code highlight]
    builder = StateGraph(...)
    graph = builder.compile(checkpointer=checkpointer)  # [!code highlight]

pip install -U "psycopg[binary,pool]" langgraph langgraph-checkpoint-postgres

  ```python
  from langchain.chat_models import init_chat_model
  from langgraph.graph import StateGraph, MessagesState, START
  from langgraph.checkpoint.postgres import PostgresSaver  # [!code highlight]

  model = init_chat_model(model="claude-haiku-4-5-20251001")

  DB_URI = "postgresql://postgres:postgres@localhost:5432/postgres?sslmode=disable"
  with PostgresSaver.from_conn_string(DB_URI) as checkpointer:  # [!code highlight]
      # checkpointer.setup()

      def call_model(state: MessagesState):
          response = model.invoke(state["messages"])
          return {"messages": response}

      builder = StateGraph(MessagesState)
      builder.add_node(call_model)
      builder.add_edge(START, "call_model")

      graph = builder.compile(checkpointer=checkpointer)  # [!code highlight]

      config = {
          "configurable": {
              "thread_id": "1"  # [!code highlight]
          }
      }

      stream = graph.stream_events(
          {"messages": [{"role": "user", "content": "hi! I'm bob"}]},
          config,  # [!code highlight]
          version="v3",
      )
      for snapshot in stream.values:
          print(snapshot)

      stream = graph.stream_events(
          {"messages": [{"role": "user", "content": "what's my name?"}]},
          config,  # [!code highlight]
          version="v3",
      )
      for snapshot in stream.values:
          print(snapshot)



### Async
      ```python
      from langchain.chat_models import init_chat_model
      from langgraph.graph import StateGraph, MessagesState, START
      from langgraph.checkpoint.postgres.aio import AsyncPostgresSaver  # [!code highlight]

      model = init_chat_model(model="claude-haiku-4-5-20251001")

      DB_URI = "postgresql://postgres:postgres@localhost:5432/postgres?sslmode=disable"
      async with AsyncPostgresSaver.from_conn_string(DB_URI) as checkpointer:  # [!code highlight]
          # await checkpointer.setup()

          async def call_model(state: MessagesState):
              response = await model.ainvoke(state["messages"])
              return {"messages": response}

          builder = StateGraph(MessagesState)
          builder.add_node(call_model)
          builder.add_edge(START, "call_model")

          graph = builder.compile(checkpointer=checkpointer)  # [!code highlight]

          config = {
              "configurable": {
                  "thread_id": "1"  # [!code highlight]
              }
          }

          stream = await graph.astream_events(
              {"messages": [{"role": "user", "content": "hi! I'm bob"}]},
              config,  # [!code highlight]
              version="v3",
          )
          async for message in stream.messages:
              async for token in message.text:
                  print(token, end="", flush=True)

          stream = await graph.astream_events(
              {"messages": [{"role": "user", "content": "what's my name?"}]},
              config,  # [!code highlight]
              version="v3",
          )
          async for message in stream.messages:
              async for token in message.text:
                  print(token, end="", flush=True)

npm install @langchain/langgraph-checkpoint-postgres

import { ChatAnthropic } from "@langchain/anthropic";
import { StateGraph, StateSchema, MessagesValue, GraphNode, START } from "@langchain/langgraph";
import { PostgresSaver } from "@langchain/langgraph-checkpoint-postgres";

const State = new StateSchema({
  messages: MessagesValue,
});

const model = new ChatAnthropic({ model: "claude-haiku-4-5-20251001" });

const DB_URI = "postgresql://postgres:postgres@localhost:5432/postgres?sslmode=disable";
const checkpointer = PostgresSaver.fromConnString(DB_URI);
// await checkpointer.setup();

const callModel: GraphNode<typeof State> = async (state) => {
  const response = await model.invoke(state.messages);
  return { messages: [response] };
};

const builder = new StateGraph(State)
  .addNode("call_model", callModel)
  .addEdge(START, "call_model");

const graph = builder.compile({ checkpointer });

const config = {
  configurable: {
    thread_id: "1"
  }
};

const stream1 = await graph.streamEvents(
  { messages: [{ role: "user", content: "hi! I'm bob" }] },
  { ...config, version: "v3" }
);
for await (const snapshot of stream1.values) {
  console.log(snapshot);
}

const stream2 = await graph.streamEvents(
  { messages: [{ role: "user", content: "what's my name?" }] },
  { ...config, version: "v3" }
);
for await (const snapshot of stream2.values) {
  console.log(snapshot);
}

pip install -U pymongo langgraph langgraph-checkpoint-mongodb

  ```python
  from langchain.chat_models import init_chat_model
  from langgraph.graph import StateGraph, MessagesState, START
  from langgraph.checkpoint.mongodb import MongoDBSaver  # [!code highlight]

  model = init_chat_model(model="claude-haiku-4-5-20251001")

  MONGODB_URI = "localhost:27017"
  with MongoDBSaver.from_conn_string(MONGODB_URI) as checkpointer:  # [!code highlight]

      def call_model(state: MessagesState):
          response = model.invoke(state["messages"])
          return {"messages": response}

      builder = StateGraph(MessagesState)
      builder.add_node(call_model)
      builder.add_edge(START, "call_model")

      graph = builder.compile(checkpointer=checkpointer)  # [!code highlight]

      config = {
          "configurable": {
              "thread_id": "1"  # [!code highlight]
          }
      }

      stream = graph.stream_events(
          {"messages": [{"role": "user", "content": "hi! I'm bob"}]},
          config,  # [!code highlight]
          version="v3",
      )
      for snapshot in stream.values:
          print(snapshot)

      stream = graph.stream_events(
          {"messages": [{"role": "user", "content": "what's my name?"}]},
          config,  # [!code highlight]
          version="v3",
      )
      for snapshot in stream.values:
          print(snapshot)



### Async
      ```python
      from langchain.chat_models import init_chat_model
      from langgraph.graph import StateGraph, MessagesState, START
      from langgraph.checkpoint.mongodb.aio import AsyncMongoDBSaver  # [!code highlight]

      model = init_chat_model(model="claude-haiku-4-5-20251001")

      MONGODB_URI = "localhost:27017"
      async with AsyncMongoDBSaver.from_conn_string(MONGODB_URI) as checkpointer:  # [!code highlight]

          async def call_model(state: MessagesState):
              response = await model.ainvoke(state["messages"])
              return {"messages": response}

          builder = StateGraph(MessagesState)
          builder.add_node(call_model)
          builder.add_edge(START, "call_model")

          graph = builder.compile(checkpointer=checkpointer)  # [!code highlight]

          config = {
              "configurable": {
                  "thread_id": "1"  # [!code highlight]
              }
          }

          stream = await graph.astream_events(
              {"messages": [{"role": "user", "content": "hi! I'm bob"}]},
              config,  # [!code highlight]
              version="v3",
          )
          async for message in stream.messages:
              async for token in message.text:
                  print(token, end="", flush=True)

          stream = await graph.astream_events(
              {"messages": [{"role": "user", "content": "what's my name?"}]},
              config,  # [!code highlight]
              version="v3",
          )
          async for message in stream.messages:
              async for token in message.text:
                  print(token, end="", flush=True)

npm install @langchain/langgraph-checkpoint-mongodb

import { ChatAnthropic } from "@langchain/anthropic";
import { StateGraph, StateSchema, MessagesValue, GraphNode, START } from "@langchain/langgraph";
import { MongoDBSaver } from "@langchain/langgraph-checkpoint-mongodb";
import { MongoClient } from "mongodb";

const State = new StateSchema({
  messages: MessagesValue,
});

const model = new ChatAnthropic({ model: "claude-haiku-4-5-20251001" });

const client = new MongoClient("mongodb://user:password@localhost:27017");
const checkpointer = new MongoDBSaver({ client, dbName: "langgraph" });

const callModel: GraphNode<typeof State> = async (state) => {
  const response = await model.invoke(state.messages);
  return { messages: [response] };
};

const builder = new StateGraph(State)
  .addNode("call_model", callModel)
  .addEdge(START, "call_model");

const graph = builder.compile({ checkpointer });

const config = { configurable: { thread_id: "1" } };

const stream1 = await graph.streamEvents(
  { messages: [{ role: "user", content: "hi! I'm bob" }] },
  { ...config, version: "v3" }
);
for await (const snapshot of stream1.values) {
  console.log(snapshot);
}

const stream2 = await graph.streamEvents(
  { messages: [{ role: "user", content: "what's my name?" }] },
  { ...config, version: "v3" }
);
for await (const snapshot of stream2.values) {
  console.log(snapshot);
}

pip install -U langgraph langgraph-checkpoint-redis

  ```python
  from langchain.chat_models import init_chat_model
  from langgraph.graph import StateGraph, MessagesState, START
  from langgraph.checkpoint.redis import RedisSaver  # [!code highlight]

  model = init_chat_model(model="claude-haiku-4-5-20251001")

  DB_URI = "redis://localhost:6379"
  with RedisSaver.from_conn_string(DB_URI) as checkpointer:  # [!code highlight]
      # checkpointer.setup()

      def call_model(state: MessagesState):
          response = model.invoke(state["messages"])
          return {"messages": response}

      builder = StateGraph(MessagesState)
      builder.add_node(call_model)
      builder.add_edge(START, "call_model")

      graph = builder.compile(checkpointer=checkpointer)  # [!code highlight]

      config = {
          "configurable": {
              "thread_id": "1"  # [!code highlight]
          }
      }

      stream = graph.stream_events(
          {"messages": [{"role": "user", "content": "hi! I'm bob"}]},
          config,  # [!code highlight]
          version="v3",
      )
      for snapshot in stream.values:
          print(snapshot)

      stream = graph.stream_events(
          {"messages": [{"role": "user", "content": "what's my name?"}]},
          config,  # [!code highlight]
          version="v3",
      )
      for snapshot in stream.values:
          print(snapshot)
  ```


  ```python
  from langchain.chat_models import init_chat_model
  from langgraph.graph import StateGraph, MessagesState, START
  from langgraph.checkpoint.redis.aio import AsyncRedisSaver  # [!code highlight]

  model = init_chat_model(model="claude-haiku-4-5-20251001")

  DB_URI = "redis://localhost:6379"
  async with AsyncRedisSaver.from_conn_string(DB_URI) as checkpointer:  # [!code highlight]
      # await checkpointer.asetup()

      async def call_model(state: MessagesState):
          response = await model.ainvoke(state["messages"])
          return {"messages": response}

      builder = StateGraph(MessagesState)
      builder.add_node(call_model)
      builder.add_edge(START, "call_model")

      graph = builder.compile(checkpointer=checkpointer)  # [!code highlight]

      config = {
          "configurable": {
              "thread_id": "1"  # [!code highlight]
          }
      }

      stream = await graph.astream_events(
          {"messages": [{"role": "user", "content": "hi! I'm bob"}]},
          config,  # [!code highlight]
          version="v3",
      )
      async for message in stream.messages:
          async for token in message.text:
              print(token, end="", flush=True)

      stream = await graph.astream_events(
          {"messages": [{"role": "user", "content": "what's my name?"}]},
          config,  # [!code highlight]
          version="v3",
      )
      async for message in stream.messages:
          async for token in message.text:
              print(token, end="", flush=True)





### Example: using Oracle checkpointer

>
>     **Setup**
>     To use the [Oracle checkpointer](https://pypi.org/project/langgraph-oracledb/), you will need an Oracle AI Database instance. A local container (for example `gvenzl/oracle-free:23-slim`) or an Oracle Autonomous Database in OCI both work.

>
>     You need to call `checkpointer.setup()` the first time you're using the Oracle checkpointer.



### Sync
    ```python
    from langchain.chat_models import init_chat_model
    from langgraph.graph import StateGraph, MessagesState, START
    from langgraph_oracledb.checkpoint.oracle import OracleSaver  # [!code highlight]

    model = init_chat_model(model="claude-haiku-4-5-20251001")

    DB_URI = "user/password@localhost:1521/FREEPDB1"
    with OracleSaver.from_conn_string(DB_URI) as checkpointer:  # [!code highlight]
        # checkpointer.setup()

        def call_model(state: MessagesState):
            response = model.invoke(state["messages"])
            return {"messages": response}

        builder = StateGraph(MessagesState)
        builder.add_node(call_model)
        builder.add_edge(START, "call_model")

        graph = builder.compile(checkpointer=checkpointer)  # [!code highlight]

        config = {
            "configurable": {
                "thread_id": "1"  # [!code highlight]
            }
        }

        stream = graph.stream_events(
            {"messages": [{"role": "user", "content": "hi! I'm bob"}]},
            config,  # [!code highlight]
            version="v3",
        )
        for snapshot in stream.values:
            print(snapshot)

        stream = graph.stream_events(
            {"messages": [{"role": "user", "content": "what's my name?"}]},
            config,  # [!code highlight]
            version="v3",
        )
        for snapshot in stream.values:
            print(snapshot)

  ```python
  from langchain.chat_models import init_chat_model
  from langgraph.graph import StateGraph, MessagesState, START
  from langgraph_oracledb.checkpoint.oracle import AsyncOracleSaver  # [!code highlight]

  model = init_chat_model(model="claude-haiku-4-5-20251001")

  DB_URI = "user/password@localhost:1521/FREEPDB1"
  async with AsyncOracleSaver.from_conn_string(DB_URI) as checkpointer:  # [!code highlight]
      # await checkpointer.setup()

      async def call_model(state: MessagesState):
          response = await model.ainvoke(state["messages"])
          return {"messages": response}

      builder = StateGraph(MessagesState)
      builder.add_node(call_model)
      builder.add_edge(START, "call_model")

      graph = builder.compile(checkpointer=checkpointer)  # [!code highlight]

      config = {
          "configurable": {
              "thread_id": "1"  # [!code highlight]
          }
      }

      stream = await graph.astream_events(
          {"messages": [{"role": "user", "content": "hi! I'm bob"}]},
          config,  # [!code highlight]
          version="v3",
      )
      async for message in stream.messages:
          async for token in message.text:
              print(token, end="", flush=True)

      stream = await graph.astream_events(
          {"messages": [{"role": "user", "content": "what's my name?"}]},
          config,  # [!code highlight]
          version="v3",
      )
      async for message in stream.messages:
          async for token in message.text:
              print(token, end="", flush=True)





### Use in subgraphs

If your graph contains [subgraphs](https://docs.langchain.com/oss/langgraph/use-subgraphs), you only need to provide the checkpointer when compiling the parent graph. LangGraph will automatically propagate the checkpointer to the child subgraphs.

```python
from langgraph.graph import START, StateGraph
from langgraph.checkpoint.memory import InMemorySaver
from typing import TypedDict

class State(TypedDict):
    foo: str

# Subgraph

def subgraph_node_1(state: State):
    return {"foo": state["foo"] + "bar"}

subgraph_builder = StateGraph(State)
subgraph_builder.add_node(subgraph_node_1)
subgraph_builder.add_edge(START, "subgraph_node_1")
subgraph = subgraph_builder.compile()  # [!code highlight]

# Parent graph

builder = StateGraph(State)
builder.add_node("node_1", subgraph)  # [!code highlight]
builder.add_edge(START, "node_1")

checkpointer = InMemorySaver()
graph = builder.compile(checkpointer=checkpointer)  # [!code highlight]

subgraph_builder = StateGraph(...)
subgraph = subgraph_builder.compile(checkpointer=True)  # [!code highlight]

from langgraph.store.memory import InMemoryStore  # [!code highlight]
from langgraph.graph import StateGraph

store = InMemoryStore()  # [!code highlight]

builder = StateGraph(...)
graph = builder.compile(store=store)  # [!code highlight]

from dataclasses import dataclass
from langgraph.runtime import Runtime
from langgraph.graph import StateGraph, MessagesState, START
from langchain_core.utils.uuid import uuid7
@dataclass
class Context:
    user_id: str

async def call_model(state: MessagesState, runtime: Runtime[Context]):  # [!code highlight]
    user_id = runtime.context.user_id  # [!code highlight]
    namespace = (user_id, "memories")

    # Search for relevant memories
    memories = await runtime.store.asearch(  # [!code highlight]
        namespace, query=state["messages"][-1].content, limit=3
    )
    info = "\n".join([d.value["data"] for d in memories])

    # ... Use memories in model call

    # Store a new memory
    await runtime.store.aput(  # [!code highlight]
        namespace, str(uuid7()), {"data": "User prefers dark mode"}
    )

builder = StateGraph(MessagesState, context_schema=Context)  # [!code highlight]
builder.add_node(call_model)
builder.add_edge(START, "call_model")
graph = builder.compile(store=store)

# Pass context at invocation time
graph.invoke(
    {"messages": [{"role": "user", "content": "hi"}]},
    {"configurable": {"thread_id": "1"}},
    context=Context(user_id="1"),  # [!code highlight]
)

from langgraph.store.postgres import PostgresStore

DB_URI = "postgresql://postgres:postgres@localhost:5432/postgres?sslmode=disable"
with PostgresStore.from_conn_string(DB_URI) as store:  # [!code highlight]
    builder = StateGraph(...)
    graph = builder.compile(store=store)  # [!code highlight]

pip install -U "psycopg[binary,pool]" langgraph langgraph-checkpoint-postgres

  ```python
  from dataclasses import dataclass
  from langchain.chat_models import init_chat_model
  from langgraph.graph import StateGraph, MessagesState, START
  from langgraph.checkpoint.postgres.aio import AsyncPostgresSaver
  from langgraph.store.postgres.aio import AsyncPostgresStore  # [!code highlight]
  from langgraph.runtime import Runtime  # [!code highlight]

  model = init_chat_model(model="claude-haiku-4-5-20251001")

  @dataclass
  class Context:
      user_id: str

  async def call_model(  # [!code highlight]
      state: MessagesState,
      runtime: Runtime[Context],  # [!code highlight]
  ):
      user_id = runtime.context.user_id  # [!code highlight]
      namespace = ("memories", user_id)
      memories = await runtime.store.asearch(namespace, query=str(state["messages"][-1].content))  # [!code highlight]
      info = "\n".join([d.value["data"] for d in memories])
      system_msg = f"You are a helpful assistant talking to the user. User info: {info}"

      # Store new memories if the user asks the model to remember
      last_message = state["messages"][-1]
      if "remember" in last_message.content.lower():
          memory = "User name is Bob"
          await runtime.store.aput(namespace, str(uuid7()), {"data": memory})  # [!code highlight]

      response = await model.ainvoke(
          [{"role": "system", "content": system_msg}] + state["messages"]
      )
      return {"messages": response}

  DB_URI = "postgresql://postgres:postgres@localhost:5432/postgres?sslmode=disable"

  async with (
      AsyncPostgresStore.from_conn_string(DB_URI) as store,  # [!code highlight]
      AsyncPostgresSaver.from_conn_string(DB_URI) as checkpointer,
  ):
      # await store.setup()
      # await checkpointer.setup()

      builder = StateGraph(MessagesState, context_schema=Context)  # [!code highlight]
      builder.add_node(call_model)
      builder.add_edge(START, "call_model")

      graph = builder.compile(
          checkpointer=checkpointer,
          store=store,  # [!code highlight]
      )

      config = {"configurable": {"thread_id": "1"}}
      stream = await graph.astream_events(
          {"messages": [{"role": "user", "content": "Hi! Remember: my name is Bob"}]},
          config,
          version="v3",
          context=Context(user_id="1"),  # [!code highlight]
      )
      async for message in stream.messages:
          async for token in message.text:
              print(token, end="", flush=True)

      config = {"configurable": {"thread_id": "2"}}
      stream = await graph.astream_events(
          {"messages": [{"role": "user", "content": "what is my name?"}]},
          config,
          version="v3",
          context=Context(user_id="1"),  # [!code highlight]
      )
      async for message in stream.messages:
          async for token in message.text:
              print(token, end="", flush=True)



### Sync
      ```python
      from dataclasses import dataclass
      from langchain.chat_models import init_chat_model
      from langgraph.graph import StateGraph, MessagesState, START
      from langgraph.checkpoint.postgres import PostgresSaver
      from langgraph.store.postgres import PostgresStore  # [!code highlight]
      from langgraph.runtime import Runtime  # [!code highlight]

      model = init_chat_model(model="claude-haiku-4-5-20251001")

      @dataclass
      class Context:
          user_id: str

      def call_model(  # [!code highlight]
          state: MessagesState,
          runtime: Runtime[Context],  # [!code highlight]
      ):
          user_id = runtime.context.user_id  # [!code highlight]
          namespace = ("memories", user_id)
          memories = runtime.store.search(namespace, query=str(state["messages"][-1].content))  # [!code highlight]
          info = "\n".join([d.value["data"] for d in memories])
          system_msg = f"You are a helpful assistant talking to the user. User info: {info}"

          # Store new memories if the user asks the model to remember
          last_message = state["messages"][-1]
          if "remember" in last_message.content.lower():
              memory = "User name is Bob"
              runtime.store.put(namespace, str(uuid7()), {"data": memory})  # [!code highlight]

          response = model.invoke(
              [{"role": "system", "content": system_msg}] + state["messages"]
          )
          return {"messages": response}

      DB_URI = "postgresql://postgres:postgres@localhost:5432/postgres?sslmode=disable"

      with (
          PostgresStore.from_conn_string(DB_URI) as store,  # [!code highlight]
          PostgresSaver.from_conn_string(DB_URI) as checkpointer,
      ):
          # store.setup()
          # checkpointer.setup()

          builder = StateGraph(MessagesState, context_schema=Context)  # [!code highlight]
          builder.add_node(call_model)
          builder.add_edge(START, "call_model")

          graph = builder.compile(
              checkpointer=checkpointer,
              store=store,  # [!code highlight]
          )

          config = {"configurable": {"thread_id": "1"}}
          stream = graph.stream_events(
              {"messages": [{"role": "user", "content": "Hi! Remember: my name is Bob"}]},
              config,
              version="v3",
              context=Context(user_id="1"),  # [!code highlight]
          )
          for snapshot in stream.values:
              print(snapshot)

          config = {"configurable": {"thread_id": "2"}}
          stream = graph.stream_events(
              {"messages": [{"role": "user", "content": "what is my name?"}]},
              config,
              version="v3",
              context=Context(user_id="1"),  # [!code highlight]
          )
          for snapshot in stream.values:
              print(snapshot)

npm install @langchain/langgraph-checkpoint-postgres

import { ChatAnthropic } from "@langchain/anthropic";
import { StateGraph, StateSchema, MessagesValue, GraphNode, START } from "@langchain/langgraph";
import { PostgresSaver } from "@langchain/langgraph-checkpoint-postgres";
import { PostgresStore } from "@langchain/langgraph-checkpoint-postgres/store";

const State = new StateSchema({
  messages: MessagesValue,
});

const model = new ChatAnthropic({ model: "claude-haiku-4-5-20251001" });

const callModel: GraphNode<typeof State> = async (state, runtime) => {
  const userId = runtime.context?.userId;
  const namespace = ["memories", userId];
  const memories = await runtime.store?.search(namespace, { query: state.messages.at(-1)?.content });
  const info = memories?.map(d => d.value.data).join("\n") || "";
  const systemMsg = `You are a helpful assistant talking to the user. User info: ${info}`;

  // Store new memories if the user asks the model to remember
  const lastMessage = state.messages.at(-1);
  if (lastMessage?.content?.toLowerCase().includes("remember")) {
    const memory = "User name is Bob";
    await runtime.store?.put(namespace, uuid7(), { data: memory });
  }

  const response = await model.invoke([
    { role: "system", content: systemMsg },
    ...state.messages
  ]);
  return { messages: [response] };
};

const DB_URI = "postgresql://postgres:postgres@localhost:5432/postgres?sslmode=disable";

const store = PostgresStore.fromConnString(DB_URI);
const checkpointer = PostgresSaver.fromConnString(DB_URI);
// await store.setup();
// await checkpointer.setup();

const builder = new StateGraph(State)
  .addNode("call_model", callModel)
  .addEdge(START, "call_model");

const graph = builder.compile({
  checkpointer,
  store,
});

const stream1 = await graph.streamEvents(
  { messages: [{ role: "user", content: "Hi! Remember: my name is Bob" }] },
  { configurable: { thread_id: "1" }, context: { userId: "1" }, version: "v3" }
);
for await (const snapshot of stream1.values) {
  console.log(snapshot);
}

const stream2 = await graph.streamEvents(
  { messages: [{ role: "user", content: "what is my name?" }] },
  { configurable: { thread_id: "2" }, context: { userId: "1" }, version: "v3" }
);
for await (const snapshot of stream2.values) {
  console.log(snapshot);
}

npm install @langchain/langgraph-checkpoint-mongodb

import { ChatAnthropic } from "@langchain/anthropic";
import { MemorySaver, StateGraph, StateSchema, MessagesValue, GraphNode, START } from "@langchain/langgraph";
import { MongoDBStore } from "@langchain/langgraph-checkpoint-mongodb";

const State = new StateSchema({
  messages: MessagesValue,
});

const model = new ChatAnthropic({ model: "claude-sonnet-4-6" });

const callModel: GraphNode<typeof State> = async (state, runtime) => {
  const userId = runtime.context?.userId;
  const namespace = ["memories", userId];
  const memories = await runtime.store?.search(namespace);
  const info = memories?.map(d => d.value.data).join("\n") || "n/a";
  const systemMsg = `You are a helpful assistant talking to the user. User info: ${info}`;

  // Store new memories if the user asks the model to remember
  const lastMessage = state.messages.at(-1);
  if (lastMessage?.content?.toLowerCase().includes("remember")) {
    const memory = "User name is Bob";
    await runtime.store?.put(namespace, uuid7(), { data: memory });
  }

  const response = await model.invoke([
    { role: "system", content: systemMsg },
    ...state.messages
  ]);
  return { messages: [response] };
};

const MONGODB_URI = "mongodb://user:password@localhost:27017";

const store = await MongoDBStore.fromConnString(MONGODB_URI, {
  dbName: "langgraph",
  collectionName: "store",
});

const checkpointer = new MemorySaver();

const builder = new StateGraph(State)
  .addNode("call_model", callModel)
  .addEdge(START, "call_model");

const graph = builder.compile({ checkpointer, store });

const stream1 = await graph.streamEvents(
  { messages: [{ role: "user", content: "Hi! Remember: my name is Bob" }] },
  { configurable: { thread_id: "1" }, context: { userId: "1" }, version: "v3" }
);
for await (const snapshot of stream1.values) {
  console.log(snapshot);
}

const stream2 = await graph.streamEvents(
  { messages: [{ role: "user", content: "what is my name?" }] },
  { configurable: { thread_id: "2" }, context: { userId: "1" }, version: "v3" }
);
for await (const snapshot of stream2.values) {
  console.log(snapshot);
}

pip install -U langgraph langgraph-checkpoint-redis

  ```python
  from dataclasses import dataclass
  from langchain.chat_models import init_chat_model
  from langgraph.graph import StateGraph, MessagesState, START
  from langgraph.checkpoint.redis.aio import AsyncRedisSaver
  from langgraph.store.redis.aio import AsyncRedisStore  # [!code highlight]
  from langgraph.runtime import Runtime  # [!code highlight]

  model = init_chat_model(model="claude-haiku-4-5-20251001")

  @dataclass
  class Context:
      user_id: str

  async def call_model(  # [!code highlight]
      state: MessagesState,
      runtime: Runtime[Context],  # [!code highlight]
  ):
      user_id = runtime.context.user_id  # [!code highlight]
      namespace = ("memories", user_id)
      memories = await runtime.store.asearch(namespace, query=str(state["messages"][-1].content))  # [!code highlight]
      info = "\n".join([d.value["data"] for d in memories])
      system_msg = f"You are a helpful assistant talking to the user. User info: {info}"

      # Store new memories if the user asks the model to remember
      last_message = state["messages"][-1]
      if "remember" in last_message.content.lower():
          memory = "User name is Bob"
          await runtime.store.aput(namespace, str(uuid7()), {"data": memory})  # [!code highlight]

      response = await model.ainvoke(
          [{"role": "system", "content": system_msg}] + state["messages"]
      )
      return {"messages": response}

  DB_URI = "redis://localhost:6379"

  async with (
      AsyncRedisStore.from_conn_string(DB_URI) as store,  # [!code highlight]
      AsyncRedisSaver.from_conn_string(DB_URI) as checkpointer,
  ):
      # await store.setup()
      # await checkpointer.asetup()

      builder = StateGraph(MessagesState, context_schema=Context)  # [!code highlight]
      builder.add_node(call_model)
      builder.add_edge(START, "call_model")

      graph = builder.compile(
          checkpointer=checkpointer,
          store=store,  # [!code highlight]
      )

      config = {"configurable": {"thread_id": "1"}}
      stream = await graph.astream_events(
          {"messages": [{"role": "user", "content": "Hi! Remember: my name is Bob"}]},
          config,
          version="v3",
          context=Context(user_id="1"),  # [!code highlight]
      )
      async for snapshot in stream.values:
          snapshot["messages"][-1].pretty_print()

      config = {"configurable": {"thread_id": "2"}}
      stream = await graph.astream_events(
          {"messages": [{"role": "user", "content": "what is my name?"}]},
          config,
          version="v3",
          context=Context(user_id="1"),  # [!code highlight]
      )
      async for snapshot in stream.values:
          snapshot["messages"][-1].pretty_print()



### Sync
      ```python
      from dataclasses import dataclass
      from langchain.chat_models import init_chat_model
      from langgraph.graph import StateGraph, MessagesState, START
      from langgraph.checkpoint.redis import RedisSaver
      from langgraph.store.redis import RedisStore  # [!code highlight]
      from langgraph.runtime import Runtime  # [!code highlight]

      model = init_chat_model(model="claude-haiku-4-5-20251001")

      @dataclass
      class Context:
          user_id: str

      def call_model(  # [!code highlight]
          state: MessagesState,
          runtime: Runtime[Context],  # [!code highlight]
      ):
          user_id = runtime.context.user_id  # [!code highlight]
          namespace = ("memories", user_id)
          memories = runtime.store.search(namespace, query=str(state["messages"][-1].content))  # [!code highlight]
          info = "\n".join([d.value["data"] for d in memories])
          system_msg = f"You are a helpful assistant talking to the user. User info: {info}"

          # Store new memories if the user asks the model to remember
          last_message = state["messages"][-1]
          if "remember" in last_message.content.lower():
              memory = "User name is Bob"
              runtime.store.put(namespace, str(uuid7()), {"data": memory})  # [!code highlight]

          response = model.invoke(
              [{"role": "system", "content": system_msg}] + state["messages"]
          )
          return {"messages": response}

      DB_URI = "redis://localhost:6379"

      with (
          RedisStore.from_conn_string(DB_URI) as store,  # [!code highlight]
          RedisSaver.from_conn_string(DB_URI) as checkpointer,
      ):
          store.setup()
          checkpointer.setup()

          builder = StateGraph(MessagesState, context_schema=Context)  # [!code highlight]
          builder.add_node(call_model)
          builder.add_edge(START, "call_model")

          graph = builder.compile(
              checkpointer=checkpointer,
              store=store,  # [!code highlight]
          )

          config = {"configurable": {"thread_id": "1"}}
          stream = graph.stream_events(
              {"messages": [{"role": "user", "content": "Hi! Remember: my name is Bob"}]},
              config,
              version="v3",
              context=Context(user_id="1"),  # [!code highlight]
          )
          for snapshot in stream.values:
              snapshot["messages"][-1].pretty_print()

          config = {"configurable": {"thread_id": "2"}}
          stream = graph.stream_events(
              {"messages": [{"role": "user", "content": "what is my name?"}]},
              config,
              version="v3",
              context=Context(user_id="1"),  # [!code highlight]
          )
          for snapshot in stream.values:
              snapshot["messages"][-1].pretty_print()

pip install -U langgraph langgraph-oracledb langchain-openai

  ```python

  from langchain.chat_models import init_chat_model
  from langchain.embeddings import init_embeddings
  from langchain_core.runnables import RunnableConfig
  from langgraph.graph import StateGraph, MessagesState, START
  from langgraph.store.base import BaseStore
  from langgraph_oracledb.checkpoint.oracle import OracleSaver
  from langgraph_oracledb.store.oracle import OracleStore  # [!code highlight]

  model = init_chat_model(model="claude-haiku-4-5-20251001")
  embeddings = init_embeddings("openai:text-embedding-3-small")

  DB_URI = "user/password@localhost:1521/FREEPDB1"

  with (
      OracleStore.from_conn_string(  # [!code highlight]
          DB_URI,
          index={"embed": embeddings, "dims": 1536},  # [!code highlight]
      ) as store,
      OracleSaver.from_conn_string(DB_URI) as checkpointer,
  ):
      store.setup()
      checkpointer.setup()

      def call_model(
          state: MessagesState,
          config: RunnableConfig,
          *,
          store: BaseStore,  # [!code highlight]
      ):
          user_id = config["configurable"]["user_id"]
          namespace = ("memories", user_id)
          memories = store.search(namespace, query=str(state["messages"][-1].content))  # [!code highlight]
          info = "\n".join([d.value["data"] for d in memories])
          system_msg = f"You are a helpful assistant talking to the user. User info: {info}"

          # Store new memories if the user asks the model to remember
          last_message = state["messages"][-1]
          if "remember" in last_message.content.lower():
              memory = "User name is Bob"
              store.put(namespace, str(uuid7()), {"data": memory})  # [!code highlight]

          response = model.invoke(
              [{"role": "system", "content": system_msg}] + state["messages"]
          )
          return {"messages": response}

      builder = StateGraph(MessagesState)
      builder.add_node(call_model)
      builder.add_edge(START, "call_model")

      graph = builder.compile(
          checkpointer=checkpointer,
          store=store,  # [!code highlight]
      )

      config = {
          "configurable": {
              "thread_id": "1",  # [!code highlight]
              "user_id": "1",  # [!code highlight]
          }
      }
      stream = graph.stream_events(
          {"messages": [{"role": "user", "content": "Hi! Remember: my name is Bob"}]},
          config,  # [!code highlight]
          version="v3",
      )
      for snapshot in stream.values:
          snapshot["messages"][-1].pretty_print()

      config = {
          "configurable": {
              "thread_id": "2",  # [!code highlight]
              "user_id": "1",
          }
      }

      stream = graph.stream_events(
          {"messages": [{"role": "user", "content": "what is my name?"}]},
          config,  # [!code highlight]
          version="v3",
      )
      for snapshot in stream.values:
          snapshot["messages"][-1].pretty_print()



### Async
      ```python

      from langchain.chat_models import init_chat_model
      from langchain.embeddings import init_embeddings
      from langchain_core.runnables import RunnableConfig
      from langgraph.graph import StateGraph, MessagesState, START
      from langgraph.store.base import BaseStore
      from langgraph_oracledb.checkpoint.oracle import AsyncOracleSaver
      from langgraph_oracledb.store.oracle import AsyncOracleStore  # [!code highlight]

      model = init_chat_model(model="claude-haiku-4-5-20251001")
      embeddings = init_embeddings("openai:text-embedding-3-small")

      DB_URI = "user/password@localhost:1521/FREEPDB1"

      async with (
          AsyncOracleStore.from_conn_string(  # [!code highlight]
              DB_URI,
              index={"embed": embeddings, "dims": 1536},  # [!code highlight]
          ) as store,
          AsyncOracleSaver.from_conn_string(DB_URI) as checkpointer,
      ):
          await store.setup()
          await checkpointer.setup()

          async def call_model(
              state: MessagesState,
              config: RunnableConfig,
              *,
              store: BaseStore,  # [!code highlight]
          ):
              user_id = config["configurable"]["user_id"]
              namespace = ("memories", user_id)
              memories = await store.asearch(namespace, query=str(state["messages"][-1].content))  # [!code highlight]
              info = "\n".join([d.value["data"] for d in memories])
              system_msg = f"You are a helpful assistant talking to the user. User info: {info}"

              # Store new memories if the user asks the model to remember
              last_message = state["messages"][-1]
              if "remember" in last_message.content.lower():
                  memory = "User name is Bob"
                  await store.aput(namespace, str(uuid7()), {"data": memory})  # [!code highlight]

              response = await model.ainvoke(
                  [{"role": "system", "content": system_msg}] + state["messages"]
              )
              return {"messages": response}

          builder = StateGraph(MessagesState)
          builder.add_node(call_model)
          builder.add_edge(START, "call_model")

          graph = builder.compile(
              checkpointer=checkpointer,
              store=store,  # [!code highlight]
          )

          config = {
              "configurable": {
                  "thread_id": "1",  # [!code highlight]
                  "user_id": "1",  # [!code highlight]
              }
          }
          stream = await graph.astream_events(
              {"messages": [{"role": "user", "content": "Hi! Remember: my name is Bob"}]},
              config,  # [!code highlight]
              version="v3",
          )
          async for snapshot in stream.values:
              snapshot["messages"][-1].pretty_print()

          config = {
              "configurable": {
                  "thread_id": "2",  # [!code highlight]
                  "user_id": "1",
              }
          }

          stream = await graph.astream_events(
              {"messages": [{"role": "user", "content": "what is my name?"}]},
              config,  # [!code highlight]
              version="v3",
          )
          async for snapshot in stream.values:
              snapshot["messages"][-1].pretty_print()

from langchain.embeddings import init_embeddings
from langgraph.store.memory import InMemoryStore

# Create store with semantic search enabled
embeddings = init_embeddings("openai:text-embedding-3-small")
store = InMemoryStore(
    index={
        "embed": embeddings,
        "dims": 1536,
    }
)

store.put(("user_123", "memories"), "1", {"text": "I love pizza"})
store.put(("user_123", "memories"), "2", {"text": "I am a plumber"})

items = store.search(
    ("user_123", "memories"), query="I'm hungry", limit=1
)

:::python

```python

from langchain.embeddings import init_embeddings
from langchain.chat_models import init_chat_model
from langgraph.store.memory import InMemoryStore
from langgraph.graph import START, MessagesState, StateGraph
from langgraph.runtime import Runtime  # [!code highlight]

model = init_chat_model("gpt-5.4-mini")

# Create store with semantic search enabled
embeddings = init_embeddings("openai:text-embedding-3-small")
store = InMemoryStore(
    index={
        "embed": embeddings,
        "dims": 1536,
    }
)

store.put(("user_123", "memories"), "1", {"text": "I love pizza"})
store.put(("user_123", "memories"), "2", {"text": "I am a plumber"})

async def chat(state: MessagesState, runtime: Runtime):  # [!code highlight]
    # Search based on user's last message
    items = await runtime.store.asearch(  # [!code highlight]
        ("user_123", "memories"), query=state["messages"][-1].content, limit=2
    )
    memories = "\n".join(item.value["text"] for item in items)
    memories = f"## Memories of user\n{memories}" if memories else ""
    response = await model.ainvoke(
        [
            {"role": "system", "content": f"You are a helpful assistant.\n{memories}"},
            *state["messages"],
        ]
    )
    return {"messages": [response]}


builder = StateGraph(MessagesState)
builder.add_node(chat)
builder.add_edge(START, "chat")
graph = builder.compile(store=store)

stream = await graph.astream_events(
    {"messages": [{"role": "user", "content": "I'm hungry"}]},
    version="v3",
)
async for message in stream.messages:
    async for token in message.text:
        print(token, end="", flush=True)
```
:::

:::js

    ```typescript
    import { OpenAIEmbeddings, ChatOpenAI } from "@langchain/openai";
    import { StateGraph, StateSchema, MessagesValue, GraphNode, START, InMemoryStore } from "@langchain/langgraph";

    const State = new StateSchema({
      messages: MessagesValue,
    });

    const model = new ChatOpenAI({ model: "gpt-5.4-mini" });

    // Create store with semantic search enabled
    const embeddings = new OpenAIEmbeddings({ model: "text-embedding-3-small" });
    const store = new InMemoryStore({
      index: {
        embeddings,
        dims: 1536,
      }
    });

    await store.put(["user_123", "memories"], "1", { text: "I love pizza" });
    await store.put(["user_123", "memories"], "2", { text: "I am a plumber" });

    const chat: GraphNode<typeof State> = async (state, runtime) => {
      // Search based on user's last message
      const items = await runtime.store.search(
        ["user_123", "memories"],
        { query: state.messages.at(-1)?.content, limit: 2 }
      );
      const memories = items.map(item => item.value.text).join("\n");
      const memoriesText = memories ? `## Memories of user\n${memories}` : "";

      const response = await model.invoke([
        { role: "system", content: `You are a helpful assistant.\n${memoriesText}` },
        ...state.messages,
      ]);

      return { messages: [response] };
    };

    const builder = new StateGraph(State)
      .addNode("chat", chat)
      .addEdge(START, "chat");
    const graph = builder.compile({ store });

    const stream = await graph.streamEvents(
      { messages: [{ role: "user", content: "I'm hungry" }] },
      { version: "v3" }
    );
    for await (const message of stream.messages) {
      for await (const token of message.text) {
        process.stdout.write(token);
      }
    }
    ```


    ```typescript
    import { ChatOpenAI, OpenAIEmbeddings } from "@langchain/openai";
    import { MongoDBStore } from "@langchain/langgraph-checkpoint-mongodb";
    import { StateGraph, StateSchema, MessagesValue, GraphNode, START } from "@langchain/langgraph";

    const State = new StateSchema({
      messages: MessagesValue,
    });

    const model = new ChatOpenAI({ model: "gpt-5.4-mini" });

    // Create store with semantic search enabled
    const MONGODB_URI = "mongodb://user:password@localhost:27017";
    const store = await MongoDBStore.fromConnString(MONGODB_URI, {
      dbName: "langgraph",
      collectionName: "store",
      embeddings: new OpenAIEmbeddings({ model: "text-embedding-3-small" }),
      indexConfig: {
        name: "store_vector_index",
        dims: 1536,
        embeddingKey: "text",
      },
    });

    await store.put(["user_123", "memories"], "1", { text: "I love pizza" });
    await store.put(["user_123", "memories"], "2", { text: "I am a plumber" });

    const chat: GraphNode<typeof State> = async (state, runtime) => {
      // Search based on user's last message
      const items = await runtime.store.search(
        ["user_123", "memories"],
        { query: state.messages.at(-1)?.content, limit: 2 }
      );
      const memories = items.map(item => item.value.text).join("\n");
      const memoriesText = memories ? `## Memories of user\n${memories}` : "";

      const response = await model.invoke([
        { role: "system", content: `You are a helpful assistant.\n${memoriesText}` },
        ...state.messages,
      ]);

      return { messages: [response] };
    };

    const builder = new StateGraph(State)
      .addNode("chat", chat)
      .addEdge(START, "chat");
    const graph = builder.compile({ store });

    const stream = await graph.streamEvents(
      { messages: [{ role: "user", content: "I'm hungry" }] },
      { version: "v3" }
    );
    for await (const message of stream.messages) {
      for await (const token of message.text) {
        process.stdout.write(token);
      }
    }
    ```


    ```typescript
    import { StateGraph, StateSchema, MessagesValue, GraphNode, START } from "@langchain/langgraph";
    import { MongoDBStore } from "@langchain/langgraph-checkpoint-mongodb";
    import { ChatOpenAI } from "@langchain/openai";

    const State = new StateSchema({
      messages: MessagesValue,
    });

    const model = new ChatOpenAI({ model: "gpt-5.4-mini" });

    // Auto embedding: no embeddings instance needed.
    // Configure the Voyage AI model and the field path MongoDB will read server-side.
    const MONGODB_URI = "mongodb://user:password@localhost:27017";
    const store = await MongoDBStore.fromConnString(MONGODB_URI, {
      dbName: "langgraph",
      collectionName: "store",
      indexConfig: {
        name: "store_vector_index",
        path: "value.content",  // MongoDB reads this field and embeds it server-side
        model: "voyage-4",      // Voyage AI model used by MongoDB Atlas
      },
    });

    // Values must have the content field matching the configured path (value.content)
    await store.put(["user_123", "memories"], "1", { content: "I love pizza" });
    await store.put(["user_123", "memories"], "2", { content: "I am a plumber" });

    const chat: GraphNode<typeof State> = async (state, runtime) => {
      // MongoDB generates the query embedding server-side
      const items = await runtime.store.search(
        ["user_123", "memories"],
        { query: state.messages.at(-1)?.content, limit: 2 }
      );
      const memories = items.map(item => item.value.content).join("\n");
      const memoriesText = memories ? `## Memories of user\n${memories}` : "";

      const response = await model.invoke([
        { role: "system", content: `You are a helpful assistant.\n${memoriesText}` },
        ...state.messages,
      ]);

      return { messages: [response] };
    };

    const builder = new StateGraph(State)
      .addNode("chat", chat)
      .addEdge(START, "chat");
    const graph = builder.compile({ store });

    const stream = await graph.streamEvents(
      { messages: [{ role: "user", content: "I'm hungry" }] },
      { version: "v3" }
    );
    for await (const message of stream.messages) {
      for await (const token of message.text) {
        process.stdout.write(token);
      }
    }
    ```


:::

from langchain_core.messages.utils import (  # [!code highlight]
    trim_messages,  # [!code highlight]
    count_tokens_approximately  # [!code highlight]
)  # [!code highlight]

def call_model(state: MessagesState):
    messages = trim_messages(  # [!code highlight]
        state["messages"],
        strategy="last",
        token_counter=count_tokens_approximately,
        max_tokens=128,
        start_on="human",
        end_on=("human", "tool"),
    )
    response = model.invoke(messages)
    return {"messages": [response]}

builder = StateGraph(MessagesState)
builder.add_node(call_model)
...

from langchain_core.messages.utils import (
    trim_messages,  # [!code highlight]
    count_tokens_approximately  # [!code highlight]
)
from langchain.chat_models import init_chat_model
from langgraph.graph import StateGraph, START, MessagesState

model = init_chat_model("claude-sonnet-4-6")
summarization_model = model.bind(max_tokens=128)

def call_model(state: MessagesState):
    messages = trim_messages(  # [!code highlight]
        state["messages"],
        strategy="last",
        token_counter=count_tokens_approximately,
        max_tokens=128,
        start_on="human",
        end_on=("human", "tool"),
    )
    response = model.invoke(messages)
    return {"messages": [response]}

checkpointer = InMemorySaver()
builder = StateGraph(MessagesState)
builder.add_node(call_model)
builder.add_edge(START, "call_model")
graph = builder.compile(checkpointer=checkpointer)

config = {"configurable": {"thread_id": "1"}}
graph.invoke({"messages": "hi, my name is bob"}, config)
graph.invoke({"messages": "write a short poem about cats"}, config)
graph.invoke({"messages": "now do the same but for dogs"}, config)
final_response = graph.invoke({"messages": "what's my name?"}, config)

final_response["messages"][-1].pretty_print()

================================== Ai Message ==================================

Your name is Bob, as you mentioned when you first introduced yourself.

import { trimMessages } from "@langchain/core/messages";
import { ChatAnthropic } from "@langchain/anthropic";
import { StateGraph, StateSchema, MessagesValue, GraphNode, START, MemorySaver } from "@langchain/langgraph";

const State = new StateSchema({
  messages: MessagesValue,
});

const model = new ChatAnthropic({ model: "claude-sonnet-4-6" });

const callModel: GraphNode<typeof State> = async (state) => {
  const messages = trimMessages(state.messages, {
    strategy: "last",
    maxTokens: 128,
    startOn: "human",
    endOn: ["human", "tool"],
    tokenCounter: model,
  });
  const response = await model.invoke(messages);
  return { messages: [response] };
};

const checkpointer = new MemorySaver();
const builder = new StateGraph(State)
  .addNode("call_model", callModel)
  .addEdge(START, "call_model");
const graph = builder.compile({ checkpointer });

const config = { configurable: { thread_id: "1" } };
await graph.invoke({ messages: [{ role: "user", content: "hi, my name is bob" }] }, config);
await graph.invoke({ messages: [{ role: "user", content: "write a short poem about cats" }] }, config);
await graph.invoke({ messages: [{ role: "user", content: "now do the same but for dogs" }] }, config);
const finalResponse = await graph.invoke({ messages: [{ role: "user", content: "what's my name?" }] }, config);

console.log(finalResponse.messages.at(-1)?.content);

Your name is Bob, as you mentioned when you first introduced yourself.

from langchain.messages import RemoveMessage  # [!code highlight]

def delete_messages(state):
    messages = state["messages"]
    if len(messages) > 2:
        # remove the earliest two messages
        return {"messages": [RemoveMessage(id=m.id) for m in messages[:2]]}  # [!code highlight]

from langgraph.graph.message import REMOVE_ALL_MESSAGES  # [!code highlight]

def delete_messages(state):
    return {"messages": [RemoveMessage(id=REMOVE_ALL_MESSAGES)]}  # [!code highlight]

from langchain.messages import RemoveMessage  # [!code highlight]

def delete_messages(state):
    messages = state["messages"]
    if len(messages) > 2:
        # remove the earliest two messages
        return {"messages": [RemoveMessage(id=m.id) for m in messages[:2]]}  # [!code highlight]

def call_model(state: MessagesState):
    response = model.invoke(state["messages"])
    return {"messages": response}

builder = StateGraph(MessagesState)
builder.add_sequence([call_model, delete_messages])
builder.add_edge(START, "call_model")

checkpointer = InMemorySaver()
app = builder.compile(checkpointer=checkpointer)
config = {"configurable": {"thread_id": "1"}}

stream = app.stream_events(
    {"messages": [{"role": "user", "content": "hi! I'm bob"}]},
    config,
    version="v3"
)
for snapshot in stream.values:
    print([(message.type, message.content) for message in snapshot["messages"]])

stream = app.stream_events(
    {"messages": [{"role": "user", "content": "what's my name?"}]},
    config,
    version="v3"
)
for snapshot in stream.values:
    print([(message.type, message.content) for message in snapshot["messages"]])

[('human', "hi! I'm bob")]
[('human', "hi! I'm bob"), ('ai', 'Hi Bob! How are you doing today? Is there anything I can help you with?')]
[('human', "hi! I'm bob"), ('ai', 'Hi Bob! How are you doing today? Is there anything I can help you with?'), ('human', "what's my name?")]
[('human', "hi! I'm bob"), ('ai', 'Hi Bob! How are you doing today? Is there anything I can help you with?'), ('human', "what's my name?"), ('ai', 'Your name is Bob.')]
[('human', "what's my name?"), ('ai', 'Your name is Bob.')]

import { RemoveMessage } from "@langchain/core/messages";
import { ChatAnthropic } from "@langchain/anthropic";
import { StateGraph, StateSchema, MessagesValue, GraphNode, START, MemorySaver } from "@langchain/langgraph";

const State = new StateSchema({
  messages: MessagesValue,
});

const model = new ChatAnthropic({ model: "claude-sonnet-4-6" });

const deleteMessages: GraphNode<typeof State> = (state) => {
  const messages = state.messages;
  if (messages.length > 2) {
    // remove the earliest two messages
    return { messages: messages.slice(0, 2).map(m => new RemoveMessage({ id: m.id })) };
  }
  return {};
};

const callModel: GraphNode<typeof State> = async (state) => {
  const response = await model.invoke(state.messages);
  return { messages: [response] };
};

const builder = new StateGraph(State)
  .addNode("call_model", callModel)
  .addNode("delete_messages", deleteMessages)
  .addEdge(START, "call_model")
  .addEdge("call_model", "delete_messages");

const checkpointer = new MemorySaver();
const app = builder.compile({ checkpointer });

const config = { configurable: { thread_id: "1" } };

const stream1 = await app.streamEvents(
  { messages: [{ role: "user", content: "hi! I'm bob" }] },
  { ...config, version: "v3" }
);
for await (const snapshot of stream1.values) {
  console.log(snapshot.messages.map(message => [message.getType(), message.content]));
}

const stream2 = await app.streamEvents(
  { messages: [{ role: "user", content: "what's my name?" }] },
  { ...config, version: "v3" }
);
for await (const snapshot of stream2.values) {
  console.log(snapshot.messages.map(message => [message.getType(), message.content]));
}

[['human', "hi! I'm bob"]]
[['human', "hi! I'm bob"], ['ai', 'Hi Bob! How are you doing today? Is there anything I can help you with?']]
[['human', "hi! I'm bob"], ['ai', 'Hi Bob! How are you doing today? Is there anything I can help you with?'], ['human', "what's my name?"]]
[['human', "hi! I'm bob"], ['ai', 'Hi Bob! How are you doing today? Is there anything I can help you with?'], ['human', "what's my name?"], ['ai', 'Your name is Bob.']]
[['human', "what's my name?"], ['ai', 'Your name is Bob.']]

from langgraph.graph import MessagesState
class State(MessagesState):
    summary: str

def summarize_conversation(state: State):

    # First, we get any existing summary
    summary = state.get("summary", "")

    # Create our summarization prompt
    if summary:

        # A summary already exists
        summary_message = (
            f"This is a summary of the conversation to date: {summary}\n\n"
            "Extend the summary by taking into account the new messages above:"
        )

    else:
        summary_message = "Create a summary of the conversation above:"

    # Add prompt to our history
    messages = state["messages"] + [HumanMessage(content=summary_message)]
    response = model.invoke(messages)

    # Delete all but the 2 most recent messages
    delete_messages = [RemoveMessage(id=m.id) for m in state["messages"][:-2]]
    return {"summary": response.content, "messages": delete_messages}

from typing import Any, TypedDict

from langchain.chat_models import init_chat_model
from langchain.messages import AnyMessage
from langchain_core.messages.utils import count_tokens_approximately
from langgraph.graph import StateGraph, START, MessagesState
from langgraph.checkpoint.memory import InMemorySaver
from langmem.short_term import SummarizationNode, RunningSummary  # [!code highlight]

model = init_chat_model("claude-sonnet-4-6")
summarization_model = model.bind(max_tokens=128)

class State(MessagesState):
    context: dict[str, RunningSummary]  # [!code highlight]

class LLMInputState(TypedDict):  # [!code highlight]
    summarized_messages: list[AnyMessage]
    context: dict[str, RunningSummary]

summarization_node = SummarizationNode(  # [!code highlight]
    token_counter=count_tokens_approximately,
    model=summarization_model,
    max_tokens=256,
    max_tokens_before_summary=256,
    max_summary_tokens=128,
)

def call_model(state: LLMInputState):  # [!code highlight]
    response = model.invoke(state["summarized_messages"])
    return {"messages": [response]}

checkpointer = InMemorySaver()
builder = StateGraph(State)
builder.add_node(call_model)
builder.add_node("summarize", summarization_node)  # [!code highlight]
builder.add_edge(START, "summarize")
builder.add_edge("summarize", "call_model")
graph = builder.compile(checkpointer=checkpointer)

# Invoke the graph
config = {"configurable": {"thread_id": "1"}}
graph.invoke({"messages": "hi, my name is bob"}, config)
graph.invoke({"messages": "write a short poem about cats"}, config)
graph.invoke({"messages": "now do the same but for dogs"}, config)
final_response = graph.invoke({"messages": "what's my name?"}, config)

final_response["messages"][-1].pretty_print()
print("\nSummary:", final_response["context"]["running_summary"].summary)

================================== Ai Message ==================================

From our conversation, I can see that you introduced yourself as Bob. That's the name you shared with me when we began talking.

Summary: In this conversation, I was introduced to Bob, who then asked me to write a poem about cats. I composed a poem titled "The Mystery of Cats" that captured cats' graceful movements, independent nature, and their special relationship with humans. Bob then requested a similar poem about dogs, so I wrote "The Joy of Dogs," which highlighted dogs' loyalty, enthusiasm, and loving companionship. Both poems were written in a similar style but emphasized the distinct characteristics that make each pet special.

import { ChatAnthropic } from "@langchain/anthropic";
import {
  SystemMessage,
  HumanMessage,
  RemoveMessage,
} from "@langchain/core/messages";
import {
  StateGraph,
  StateSchema,
  MessagesValue,
  GraphNode,
  ConditionalEdgeRouter,
  START,
  END,
  MemorySaver,
} from "@langchain/langgraph";
import * as z from "zod";

const memory = new MemorySaver();

// We will add a `summary` attribute (in addition to `messages` key)
const GraphState = new StateSchema({
  messages: MessagesValue,
  summary: z.string().default(""),
});

// We will use this model for both the conversation and the summarization
const model = new ChatAnthropic({ model: "claude-haiku-4-5-20251001" });

// Define the logic to call the model
const callModel: GraphNode<typeof GraphState> = async (state) => {
  // If a summary exists, we add this in as a system message
  const { summary } = state;
  let { messages } = state;
  if (summary) {
    const systemMessage = new SystemMessage({
      id: uuid7(),
      content: `Summary of conversation earlier: ${summary}`,
    });
    messages = [systemMessage, ...messages];
  }
  const response = await model.invoke(messages);
  // We return an object, because this will get added to the existing state
  return { messages: [response] };
};

// We now define the logic for determining whether to end or summarize the conversation
const shouldContinue: ConditionalEdgeRouter<{ InputSchema: typeof GraphState; Nodes: "summarize_conversation" }> = (state) => {
  const messages = state.messages;
  // If there are more than six messages, then we summarize the conversation
  if (messages.length > 6) {
    return "summarize_conversation";
  }
  // Otherwise we can just end
  return END;
};

const summarizeConversation: GraphNode<typeof GraphState> = async (state) => {
  // First, we summarize the conversation
  const { summary, messages } = state;
  let summaryMessage: string;
  if (summary) {
    // If a summary already exists, we use a different system prompt
    // to summarize it than if one didn't
    summaryMessage =
      `This is summary of the conversation to date: ${summary}\n\n` +
      "Extend the summary by taking into account the new messages above:";
  } else {
    summaryMessage = "Create a summary of the conversation above:";
  }

  const allMessages = [
    ...messages,
    new HumanMessage({ id: uuid7(), content: summaryMessage }),
  ];

  const response = await model.invoke(allMessages);

  // We now need to delete messages that we no longer want to show up
  // I will delete all but the last two messages, but you can change this
  const deleteMessages = messages
    .slice(0, -2)
    .map((m) => new RemoveMessage({ id: m.id! }));

  if (typeof response.content !== "string") {
    throw new Error("Expected a string response from the model");
  }

  return { summary: response.content, messages: deleteMessages };
};

// Define a new graph
const workflow = new StateGraph(GraphState)
  // Define the conversation node and the summarize node
  .addNode("conversation", callModel)
  .addNode("summarize_conversation", summarizeConversation)
  // Set the entrypoint as conversation
  .addEdge(START, "conversation")
  // We now add a conditional edge
  .addConditionalEdges(
    // First, we define the start node. We use `conversation`.
    // This means these are the edges taken after the `conversation` node is called.
    "conversation",
    // Next, we pass in the function that will determine which node is called next.
    shouldContinue,
  )
  // We now add a normal edge from `summarize_conversation` to END.
  // This means that after `summarize_conversation` is called, we end.
  .addEdge("summarize_conversation", END);

// Finally, we compile it!
const app = workflow.compile({ checkpointer: memory });

```python
config = {
    "configurable": {
        "thread_id": "1",  # [!code highlight]
        # optionally provide an ID for a specific checkpoint,
        # otherwise the latest checkpoint is shown
        # "checkpoint_id": "1f029ca3-1f5b-6704-8004-820c16b69a5a"  # [!code highlight]

    }
}
graph.get_state(config)  # [!code highlight]

    ```
    StateSnapshot(
        values={'messages': [HumanMessage(content="hi! I'm bob"), AIMessage(content='Hi Bob! How are you doing today?), HumanMessage(content="what's my name?"), AIMessage(content='Your name is Bob.')]}, next=(),
        config={'configurable': {'thread_id': '1', 'checkpoint_ns': '', 'checkpoint_id': '1f029ca3-1f5b-6704-8004-820c16b69a5a'}},
        metadata={
            'source': 'loop',
            'writes': {'call_model': {'messages': AIMessage(content='Your name is Bob.')}},
            'step': 4,
            'parents': {},
            'thread_id': '1'
        },
        created_at='2025-05-05T16:01:24.680462+00:00',
        parent_config={'configurable': {'thread_id': '1', 'checkpoint_ns': '', 'checkpoint_id': '1f029ca3-1790-6b0a-8003-baf965b6a38f'}},
        tasks=(),
        interrupts=()
    )
    ```


### Checkpointer API
    ```python
    config = {
        "configurable": {
            "thread_id": "1",  # [!code highlight]
            # optionally provide an ID for a specific checkpoint,
            # otherwise the latest checkpoint is shown
            # "checkpoint_id": "1f029ca3-1f5b-6704-8004-820c16b69a5a"  # [!code highlight]

        }
    }
    checkpointer.get_tuple(config)  # [!code highlight]

```
CheckpointTuple(
    config={'configurable': {'thread_id': '1', 'checkpoint_ns': '', 'checkpoint_id': '1f029ca3-1f5b-6704-8004-820c16b69a5a'}},
    checkpoint={
        'v': 3,
        'ts': '2025-05-05T16:01:24.680462+00:00',
        'id': '1f029ca3-1f5b-6704-8004-820c16b69a5a',
        'channel_versions': {'__start__': '00000000000000000000000000000005.0.5290678567601859', 'messages': '00000000000000000000000000000006.0.3205149138784782', 'branch:to:call_model': '00000000000000000000000000000006.0.14611156755133758'}, 'versions_seen': {'__input__': {}, '__start__': {'__start__': '00000000000000000000000000000004.0.5736472536395331'}, 'call_model': {'branch:to:call_model': '00000000000000000000000000000005.0.1410174088651449'}},
        'channel_values': {'messages': [HumanMessage(content="hi! I'm bob"), AIMessage(content='Hi Bob! How are you doing today?), HumanMessage(content="what's my name?"), AIMessage(content='Your name is Bob.')]},
    },
    metadata={
        'source': 'loop',
        'writes': {'call_model': {'messages': AIMessage(content='Your name is Bob.')}},
        'step': 4,
        'parents': {},
        'thread_id': '1'
    },
    parent_config={'configurable': {'thread_id': '1', 'checkpoint_ns': '', 'checkpoint_id': '1f029ca3-1790-6b0a-8003-baf965b6a38f'}},
    pending_writes=[]
)
```
